48" Ultimate Under Bench Wine Fridge and Bar Refrigerator Combo with 3 Temp. Zones
SIZE: 46.84” W x 22.75” D x 32.87” H, included stand height 0.59”
USE CASE: The most versatile, triple temperature zones for all your drinks on hand when you want them
NOTE: Set of two units, use side by side or separately.
Quick Overview:
The 48" Ultimate Under-Bench Wine Fridge and Bar Refrigerator Combo is the perfect blend of style and functionality for any home or commercial space. Designed with two separate sections, the wine cooler accommodates up to 48 bottles of wine while the beverage compartment stores 130 cans, ensuring that you can chill both wine and drinks in one sleek unit.
This model is powered by the Embraco Inverter Compressor, known for its ultra-quiet operation and energy-efficient performance. The innovative compressor reduces energy consumption by up to 40%, offering long-term savings without compromising on cooling performance.
The cooler features adjustable wooden and metal shelves, offering flexible storage for wine bottles, cans, and other beverages. With its low-emissivity (Low-E) glass door, your drinks are protected from harmful UV rays while maintaining the unit’s energy efficiency.
Whether used as a built-in or freestanding unit, this cooler seamlessly fits into your home or bar. The sleek stainless steel finish and modern design make it both a functional and aesthetic addition to any space.
Specifications
Specifications
| Volume: | 10.24 CF (145 Liters) Total, 5.12CF (145 Liters) Each |
| Capacity (by bottles): | 46 bottles |
| Capacity (by cans): | 161 cans |
| Installation Type: | Built-In or Freestanding |
| Climate Type: | N |
| Temperature Zones: | Triple Zone |
| Adjustable Temperature Range: |
|
| Operating Room Temperature: | 32-100°F (0-38°C) |
| Shelf Configuration: | 4 Chromed Steel Shelves + 6 Beech Wooden Shelves |
| Dimensions: | 46.84” W x 22.75” D x 32.87” H, included stand height 0.59” |
Electrical
| Compressor: | Embraco Inverter Compressors |
| Rated Power Input: | 200W (100W per unit) |
| Rated Current: | 2.4A (1.2A per unit) |
| Refrigerant: | R600A / 25g per unit |
| Energy Efficiency Standard Compliance: | ETL/DOE |
Technical Features
Inverter Compressor
Top brand Embraco Inverter Compressor;
Super quiet operation and reduces energy consumption by 40%.
Patented Sink of Compressor
Increases air circulation space around the compressor;
Provides better cooling performance, less vibration, and reduced noise.
Low-E Glass
Reduces energy consumption and condensation on the glass door;
Acts as an invisible insulating barrier.
Note: Low-E Glass features a thin coating that reduces heat transfer and condensation, enhancing energy efficiency and cooling performance.
Fan Circulated Air-Cooling System
Ensures temperature uniformity in the cabinet;
Compensates for air humidity to protect contents.
Activated Carbon Filter
Effectively filters impurities in the air;
Keeps the air in the cabinet fresh and odor-free.
LED Display Digital Touchpad Control
Simple and easy-to-operate controls;
Clear and accurate settings display.
Beech Wooden Shelf
Optimized FULL-EXTENSION pull-out wood shelves with sturdy and wine-friendly beech; Cleverly spaced to fit both regular and larger bottles up to 3.39" (86mm) in diameter.
Magnetic Switch
Aggressive light control with a 2-minute door-open alarm.
Hidden Door Hinge
Laminated steel plate with integrated molding;
Full built-in design for seamless integration.
Seamless Stainless Steel Door Frame
Features an artistic appearance with a thin door design.
45mm Thickness C-Pantane
Thicker foam optimizes cooling performance and reduces energy consumption.
Dimensions & Diagrams
Technical Dimensions
Installation Diagrams
User Instruction
This manual covers a combo set of two units: a Beverage Cooler and a Dual Zone Wine Cooler.
For Beverage Cooler
Key Features
- Single-zone cooling to keep drinks at their optimal serving temperatures.
- Adjustable temperature range: 35°F to 68°F (2°C to 20°C).
- Powered by energy-efficient EMBRACO Inverter compressors for reliable cooling.
User Manual
Download the Beverage Cooler User Manual (KBU145BX/KBU265BX/KBU425BX) .
For Dual Zone Wine Cooler
Key Features
- Dual-zone cooling for storing red and white wine at optimal temperatures.
- Adjustable temperature range for upper and lower zones
- Upper Zone 35°F to 54°F (2°C to 12°C);
- Lower Zone 54°F to 68°F ( 12°C to 20°C ).
- Energy-efficient cooling with advanced EMBRACO Inverter compressors.
User Manual
Download the Dual Zone Wine Cooler User Manual (KBU145DX/KBU265DX/KBU425DX)
Choose options
Recently viewed products
Customer Reviews
We love the looks are home is still in the building process haven’t installed it yet!
Everything you could want in a beverage cooler. Digital display to tell what it set at and what the temp is currently. The wine cooler is great. No issues except one slightly bigger than normal bottle wouldn’t fit. So if you have anything slightly larger than regular bottle. Your are very limited on where you can put it. The beverage cooler the shelves could be a little better quality. One came slightly bent easily Fixed. Also I just wish you could have a more options when it came to moving the shelves height. I ended up having to take one shelve out for it to work. The glass front fridge is so you can see what’s in there before opening it. The shelf layout is made for beers and drinks to lay down. And the shelves are more like drawers. Shrinking the amount of drinks you can put it in it. Considering what the price is didn’t think that any of those would be an issue. Otherwise. Gets your beverages cold and quickly.
48 Inch Glass Door Side By Side Wine And Beverage Cooler Combo
We love the wine and beverage fridges. They are exactly what we wanted and they work perfectly.
When they first arrived one of the coolers had silver trim on the bottom and the other one had black with a silver key hole. I called and they sent out new ones right away, but the ones they sent were to small for my model . called again and they finally sent the right ones. having no instructions I took the door off and put the first one back together, it was a experience still haven't fixed the other one yet trying to move when I get in I will attempt the second one. But after all of that mess I love my coolers they look great and work awesome. thank you customer service.
The unit is the perfect combination for our new wine room. The 3 zones are amazing and work perfectly. Couldn’t be happier and would highly recommend.
We love our new 'combo' of wine refrigerator and beverage refrigerator! They provide great service and look beautiful in our new Wine Room!
Hi Bryan, thank you for the review. Good to see more and more people like our COMBO idea. If you could post a photo here and share it with us, that will be perfect.
--------
Note: received review picture. Many thanks to Bryan!
